Description

Parameter Category	VM-5H3	VM-5P3	VM-5Z4
Product Type	Vibration Sensor / Transducer	Vibration Sensor / Transducer	Vibration Sensor / Transducer
Measurement Range	0–100 mm/s	0–200 mm/s	0–50 mm/s
Frequency Range	10 Hz – 1 kHz	10 Hz – 1.5 kHz	5 Hz – 500 Hz
Sensitivity	100 mV/g	50 mV/g	200 mV/g
Output Type	Voltage	Voltage	Voltage
Supply Voltage	12–24 V DC	12–24 V DC	12–24 V DC
Signal Connector	BNC / DIN	BNC / DIN	BNC / DIN
Operating Temperature	-20°C ~ +70°C	-20°C ~ +70°C	-20°C ~ +70°C
Mounting Method	Threaded stud	Threaded stud	Threaded stud
Weight	120 g	130 g	110 g
Material	Stainless Steel	Stainless Steel	Stainless Steel
Protection Class	IP65	IP65	IP65
