Description
| Parameter Category | Specification |
|---|---|
| Model | ABB P7LA |
| Part Number | HNEF105323R0002 |
| Device Type | Protection Relay / Control Unit |
| Rated Voltage | 24–60 VDC |
| Current Rating | 5 A / 1 A (depending on configuration) |
| Frequency Range | 50–60 Hz |
| Input Channels | 4 Analog Inputs, 8 Digital Inputs |
| Output Channels | 4 Relay Outputs, 2 Analog Outputs |
| Communication Interfaces | Profibus DP, Modbus RTU, IEC 61850 optional |
| Measurement Accuracy | ±0.5% FS |
| Response Time | ≤ 20 ms |
| Display | LCD with backlight |
| Operating Temperature | -20°C – 60°C |
| Storage Temperature | -40°C – 70°C |
| Relative Humidity | 5% – 95%, non-condensing |
| Mounting | Panel mount / DIN rail optional |
| Protection Class | IP20 |
| Dimensions (HxWxD) | 144 x 144 x 160 mm |
| Weight | 1.7 kg |
| Standards Compliance | IEC 60255, IEC 61850 |
